Prensa mecánica MIOS 20to - MIOS T20FV

Recibir más información

3 + 15 =

Categories Power Press (C-Frame)

Objet 55890

Brand MIOS

Model T20 FV

YoM 2001

Press Design
drive system:  eccentric / crank
openings in uprights:  yes
number of slide actions:   1
table cushion:  no
quick die change system:  no
Press forces
total force (nominal):   20 to
Slide
spigot hole diameter:   30 mm
slide (mechan. Press)
stroke min.:   5 mm
stroke max.:   60 mm
stroke rate (min.):   60 /min
stroke rate (max.):   155 /min
Tool Assembly Dimensions
shut height (stroke down, adjustment up), BDC:   290 mm
throat (C-frame):   180 mm
Electrical specifications
total power consumption:   15 kW
mains voltage:   220 V
mains frequency:   50 Hz
Attachments (presses)
2-hand engagement:  yes
foot engagement:  yes
acc. to actual accident protection regulation:  yes
European CE standards:  yes
